제품소개

Connector

  • USB Type C (with Key Code)

    4

    Specifications

    • Pin
      24p
    • Application
      Intelligent Cockpit
      (스마트조정석)
    • Current
      1.5A DC
    • Voltage
      20V
    • Temperature
      -40°C to +105°C
    • Type
      USB Typc C 3.1

      Transmission rate: 10Gbps
      Impedeance: ReferenceUSB type c specification
      Frequency Range: DC-10GHZ
      Insertion Loss & Return Loss : Refer to cable specifications
      Contact Resistance: 40mΩ Max
      Withstanding Voltage: 200 Volts rms
  • Display Port/LVDS/USB2.0 커넥터(1)

    3

    Specifications

    • Pin
      4p
    • Application
      ▪ LVDS
      ▪ USB 2.0
      ▪ Rear Seat Connection
      ▪ Camera Connection
      ▪ Combi Instrument
      ▪ Display
    • Temperature
      -40℃ to +105℃
    • Type
      Jack, Straight
      Cable: USB 2.0 or equivalent

      Impedance: 90Ω
      Frequency range: DC-2 GHz
      Dielectric Strength Voltage: 500V rms Min
      Contact Current: ≤2.5 A DC depending on cable type
      Center Contact Resistance: 30 mΩ Max
      Outer Contact Resistance: 30 mΩ
    • 기타
      Temperature/Humidity Cycling: USCAR-2, Paragraph 5.6.2
      Vibration & Mechanical Shock: USCAR-2, Paragraph 5.4.6
      Thermal Shock: USCAR-2, Paragraph 5.6.1
      RoHS: RoHS Compliance
  • Display Port/LVDS/USB2.0 커넥터(2)

    2

    Specifications

    • Pin
      4p
    • Application
      ▪ LVDS
      ▪ USB 2.0
      ▪ Rear Seat Connection
      ▪ Camera Connection
      ▪ Combi Instrument
      ▪ Display
    • Temperature
      -40℃ to +105℃
    • Type
      Jack, Straight
      Cable: USB 2.0 or equivalent

      Impedance: 90Ω
      Frequency range: DC-2 GHz
      Dielectric Strength Voltage: 500V rms Min
      Contact Current: ≤2.5 A DC depending on cable type
      Center Contact Resistance: 30 mΩ Max
      Outer Contact Resistance: 30 mΩ
    • 기타
      Temperature/Humidity Cycling: USCAR-2, Paragraph 5.6.2
      Vibration & Mechanical Shock: USCAR-2, Paragraph 5.4.6
      Thermal Shock: USCAR-2, Paragraph 5.6.1
      RoHS: RoHS Compliance
  • Display Port/LVDS/USB2.0 커넥터(3)

    1

    Specifications

    • Pin
      4p
    • Application
      ▪ LVDS
      ▪ USB 2.0
      ▪ Rear Seat Connection
      ▪ Camera Connection
      ▪ Combi Instrument
      ▪ Display
    • Temperature
      -40℃ to +105℃
    • Type
      Jack, Straight
      Cable: USB 2.0 or equivalent

      Impedance: 90Ω
      Frequency range: DC-2 GHz
      Dielectric Strength Voltage: 500V rms Min
      Contact Current: ≤2.5 A DC depending on cable type
      Center Contact Resistance: 30 mΩ Max
      Outer Contact Resistance: 30 mΩ
    • 기타
      Temperature/Humidity Cycling: USCAR-2, Paragraph 5.6.2
      Vibration & Mechanical Shock: USCAR-2, Paragraph 5.4.6
      Thermal Shock: USCAR-2, Paragraph 5.6.1
      RoHS: RoHS Compliance
